GX-10G55-ER - XFP Transceiver

10G XFP 1550NM 40KM DDM

型号 : GX-10G55-ER
10G XFP 1550NM 40KM DDM
GZ-Link XFP ER transceiver comply with XFP 4.5MSA, and can support diverse applications for SDH/SONET equipment including FEC (9.95Gb/s to 10.7Gb/s),as well as Ethernet LAN(10.325Gb/s) and WAN(9.95Gb/s) applications.The high performance cooled 1550nm cooled EML transmitter and high sensitivity PIN receiver.

Sourcelight XFP ER transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.

XFP MSA Rev 4.5 Compliant
Data rate from 9.95Gbps to 11.3Gbps
No Reference Clock required
Cooled 1550nm EML and PIN receiver
link length up to 40km
+1.8V,+3.3V,+5V Supply Voltage
Low Power Dissipation 3.5W Maximum
XFI and lineside loopback Mode Supported
-5ºC to 70ºC Operating Case Temperature
Diagnostic Performance Monitoring of module temperature, Supply Voltages, laser bias current, transmit optical power, and receive optical power
RoHS6 compliant (lead free)
